WW-P05 · Pickup and SUV wheels
Eight-Lug Forged Pickup Wheel
Compatible heavy-duty single-rear-wheel pickups; axle load approval required.
| Wheel / rim size | 20 x 9 in (508 x 228.6 mm) |
|---|---|
| Example bolt pattern | 8 x 6.500 in (8 x 165.1 mm) |
| Example offset | 0 in (0 mm) |
| Center bore / load | Vehicle-specific approval |
Selection configuration; sample, load rating and fitment approval are required before order.
Construction & Material
Forged aluminum wheel with an eight-lug mounting pad.
Options
Finish, bore and offset within a validated design; TPMS-compatible valve option.
Size options
18 x 9 in (457.2 x 228.6 mm); 20 x 9 in (508 x 228.6 mm)
Procurement Value
Standard high-load fitments support specialized commercial distributors.
Mounting & Selection
Vehicle/year/trim, brake package, diameter/width, lug count/PCD, center bore, offset, load, TPMS and finish.
Standards & Qualification
FMVSS 110/120 applicability; SAE J2530 aftermarket test program. Fitment and test evidence are required for the supplied configuration.
Packing & Delivery
Actual packed dimensions, gross mass and stack limit to be confirmed. Protect rim edges and finished surfaces. Matched multi-piece components must be secured and identified together.
Model Approval
Confirm the quoted model, production drawing, load and fitment evidence before ordering. Reference specifications are not a supply guarantee.
